Cable Laid Grommet

(6 X WS(36) + IWRC "BG")

CABLE LAID GROMMETS TYPE

* Quality of WIRE ROPE SLING processing is one of the important elements to prevent

   industrial disasters.​

  • 케이블 레이드 그로멧 사용한계하중

※ 사용한계하중(WLL) = 단위로프절단하중 X 12가닥 X 90%(회전손실) / 안전율(사용자 선택)

(6 X WS(36) + IWRC "BG")

CABLE LAID GROMMETS TYPE

* Quality of WIRE ROPE SLING processing is one of the important elements to prevent

   industrial disasters.​

  • 케이블 레이드 슬링 사용한계하중

※ 사용한계하중(WLL) = (단위로프절단하중 X 6가닥) X 90%(회전손실) X 80%(꼬임효율) / 안전율(사용자 선택)
